Product Summary

The AOL1718 is an N-Channel Enhancement Mode Field Effect Transistor. It uses advanced trench technology with a monolithically integrated Schottky diode to provide excellent RDS(ON),and low gate charge. This AOL1718 is ideally suited for use as a low side switch in CPU core power conversion.

Parametrics

AOL1718 absolute maximum ratings: (1)Continuous Drain Current: -50A; (2)Pulsed Drain Current: -70A; (3)Gate-Source Voltage:±25V; (4)Drain-Source Voltage:-30V; (5)Junction and Storage Temperature Range:-55 to 175℃.

Features

AOL1718 features: (1)RDS(ON) < 4.3mΩ(VGS = 4.5V); (2)VDS (V) = 30V; (3)ID = 90A(VGS = 10V); (4)RDS(ON) < 3mΩ (VGS = 10V).

Diagrams

AOL1718 pin configuration

Image Part No Mfg Description Data Sheet Download Pricing
(USD)		 Quantity
AOL1718
AOL1718
Other

Data Sheet
Negotiable
