AT24C08AN-10SU-2.7

two-wire serial EEPROM device , 8-lead PDIP, 8-lead JEDEC SOIC, 8-lead MAP

Rated 5 Rating 5 | reviews | Write a review

Price:: US $0.23~0.95 / piece [Get Latest Price]

Reference price:

Qty (lots)	Price/lot
	US $0.23~0.95

PartNumber:: AT24C08AN-10SU-2.7

Brand:: ATMEL Corporation - ATMEL | Pack: DIP | D/C: 06+

Availability:: Supply Ability: 10000/Week Can Ship Immediately
Delivery: 10-15 Business Days (ships out within 3 Business days)

Quantity:: piece

Total Price:: US $0

Place Order via Escrow Service

Sold By

Ms. Sylvia Chen's store

(China (Mainland))

add to my favourite

100% Positive feedback

Detailed seller ratings

Visit Store

Contact Now

Esrcow Service

Place orders confidently and securely via it

Safe payments
Quick and easy transactions
Free service charges

Learn More >>

Previous Next

Products Upload time: 2011-03-17

From Other Seller

Part Number:AT24C08AN-10SU-2.7
US $0.23 - 0.95
AT45DB161D-SU

US $1.50 - 3.50 / Piece
(0) Remove
AT25256AW-10SU-2.7

US $0.65 - 1.50 / Piece
(0) Remove
Quantity:

piece

Product Summary

The AT24C08AN-10SU-2.7 is one member of the AT24C08A family which is designed as the two-wire serial EEPROM device that is available in space-saving 8-lead PDIP, 8-lead JEDEC SOIC, 8-lead MAP, 5-lead SOT23 (AT24C01A/ AT24C02/ AT24C04), 8-lead TSSOP, and 8-ball dBGA2 packages and is accessed via a Two-wire serial interface.

Parametrics

Absolute maximum ratings:(1)Operating Temperature: -55°C to +125°C;(2)Storage Temperature: -65°C to +150°C;(3)Voltage on Any Pin with Respect to Ground: -1.0 V to +7.0 V;(4)Maximum Operating Voltage: 6.25 V;(5)DC Output Current: 5.0 mA.

Features

Features:(1)Low-voltage and Standard-voltage Operation: 2.7 (VCC = 2.7V to 5.5V) and 1.8 (VCC = 1.8V to 5.5V);(2)Two-wire Serial Interface;(3)Schmitt Trigger, Filtered Inputs for Noise Suppression;(4)Bidirectional Data Transfer Protocol;(5)100 kHz (1.8V) and 400 kHz (2.7V, 5V) Compatibility;(6)Write Protect Pin for Hardware Data Protection;(7)8-byte Page (1K, 2K), 16-byte Page (4K, 8K, 16K) Write Modes;(8)Partial Page Writes Allowed;(9)Self-timed Write Cycle (5 ms max);(10)Automotive Grade and Lead-free/Halogen-free Devices Available;(11)Die Sales: Wafer Form, Waffle Pack and Bumped Wafers.
