Product Summary
The QM3004D is a highest performance trench N-ch mosfet with extreme high cell density, which provides excellent RDSON and gate charge for most of the synchronous buck converter applications. The applications of the QM3004D are high frequency point-of-load synchronous buck converter for MB/NB/UMPC/VGA, networking DC-DC power system, load switch.
Parametrics
QM3004D absolute maximum ratings: (1)drain-source voltage:30V; (2)continuous drain current:55, 40, 13.6, 11.4A; (3)pulsed drain current:110A; (4)single pulse avalanche energy:130mJ; (5)avalanche current:34A; (6)total power dissipation:41W; (7)storage temperature range:-55 to 175℃; (8)operating junction temperature range:-55 to 175℃.
Features
QM3004D features: (1)advanced high cell density trench technology; (2)super low gate charge; (3)excellent cdv/dt effect decline; (4)100% EAS guaranteed; (5)green device available.
Diagrams
 |
