Product Summary

The KN3906S-RTK/P is an epitaxial planar pnp transistor.

Parametrics

KN3906S-RTK/P absolute maximum ratings: (1)collector-base voltage:-40V; (2)collector-emitter voltage:-40V; (3)emitter-base voltage:-5V; (4)collector current:-200mA; (5)base current:-50mA; (6)junction temperature:150℃; (7)storage temperature range:-55 to 150℃.

Features

KN3906S-RTK/P features: (1)low leakage current:ICEX=-50nA @VCE=-30V, VEB=-3V; (2)low saturation voltage:VCE=-0.4V @IC=-50mA, IB=-5mA; (3)complementary to KN3904S.

Diagrams

KN3906S-RTK/P package dimensions
